HZS90Y Mobile Concrete Batching Plant
The DKTEC HZS90Y Mobile Concrete Batching Plant is a high-performance mobile concrete production solution designed to deliver 90 m³/h of reliable output while maintaining excellent mobility and fast deployment. Featuring a compact integrated design, a Twin Shaft Concrete Mixer, precision weighing systems, and the DKTEC Intelligent Control System, it enables quick installation, easy transportation, accurate batching, and consistent concrete quality. Combining high productivity with outstanding flexibility, the HZS90Y is an ideal choice for road construction, bridge projects, municipal engineering, infrastructure development, and temporary job sites where efficient, mobile concrete production is essential.
Briefly HZS90Y
- The HZS90Y Mobile Concrete Batching Plant is an ideal solution for construction projects that require frequent relocation or are short-term in nature. With its 2.0 m³ capacity twin-shaft mixer, the plant ensures uninterrupted production while providing excellent performance, low operating, and maintenance costs.
- Designed with practicality in mind, all units of the HZS90Y Mobile Concrete Batching Plant are mounted on a mobile chassis with axles and wheels, making it easy to transport with a single standard truck tractor. Its 2×15m³ aggregate bunker ensures efficient material storage, and it can be fed via an aggregate loading ramp or Aggregate Pre-Feeding Systems for added flexibility.
- The HZS90Y is designed to be installed quickly and requires minimal space, making it an efficient solution for projects with limited site preparation. It can be installed on zero ground, saving both time and costs, while offering significant advantages in flexibility and operational efficiency.
HZS90Y Technical Specifications
Plant Capacity
| Item | Specification |
|---|---|
| Compacted Concrete Capacity | 90 m³/hour |
Concrete Mixer
| Item | Specification |
|---|---|
| Mixer Type | Twin-Shaft Mixer |
| Mixer Motor Power | 2×30 kW |
| Mixer Capacity | 1.5 m³ / cycle (Compacted Concrete) |
Feeding System
| Item | Specification |
|---|---|
| Aggregate Bin | 2x 15 m³ |
| Aggregate Feeding | Aggregate Feeding Ramp or Pre-feeding System |
Weighing Units
| Item | Specification |
|---|---|
| Weighing System | Precision Electronic Weighing System |
Highlights
1. HZS90Y : UNMATCHED POWER FOR EXCEPTIONAL PERFORMANCE
Achieving maximum homogeneity and workability in the shortest time is essential for boosting your profits. The 1.5 m³ SICOMA/BHS Twin Shaft Concrete Mixer at the core of the HZS90Y delivers
the power and reliability you can depend on, ensuring consistent, high-quality concrete production every time.
2. SEAMLESS OPERATION WITH DKTEC AUTOMATION
DKTEC updated automation software, provides your plant operator with an intuitive interface, enhancing ease of use. It also boosts operational
efficiency with advanced documentation and archive control features, ensuring smooth and reliable plant management.
3. EASY SETUP ON ZERO GROUND LEVEL
Thanks to the newly developed steel leg system, the HZS90Y can be installed directly on zero ground without the need for a special concrete foundation. This innovative design offers a
significant cost advantage, reducing installation expenses.
